Copper Guard

Copper Guard
Copper Guard
Product Code : 01
Product Description

We are among leading entities, engaged in manufacturing, exporting and supplying premium quality Copper Guard. This product is processed under the surveillance of our skilled professionals by making use of optimum quality chemical compounds and sophisticated technology at par with international quality standards. The product provided by us is primarily used as coating on various copper metal items for protecting from corrosion. Additionally, we offer this Copper Guard in optimum quality packaging at market leading prices.

Features:

  • Purity

  • Easy to apply

  • Long shelf life

  • Highly effective

Specifications:

GENERIC TYPE

:

Two Components.

COMPOSITION

:

Chemical Resistant grade Polyamide based Rust Convertor cum Protector Top Coat for Copper Coils.

RECOMMENDED USE

:

Recommended to use coating for Copper Coil of Air Conditioner , Water Cooler , Deep Freezer, Industrial Chillers, Panel AC& Industrial Application. This product is recommended for interior application i.e. on areas not exposed to direct sunlight.

Incase Better Chemical Resistance & UV Resistance is required should be Top Coated with AS1000 TOP COAT.



PHYSICAL CONSTANTS


COLOUR

:

Transparent

FINISH

:

Semi Glossy

SOLIDS BY VOLUME

:

64 % (+-) 5% Solid Content

THEORETICAL SPREADING RATE

:

13.3 sq.mtr./ltr at 30 Microns D.F.T. on smooth & non-absorbent surface.

FLASH POINT

:

Above 25 Deg. C.

DRYING

:

DRY TO TOUCH

:

1 - 1/2

Hrs. at 25 Deg. C.

CHARACTERISTICS


DRY TO HANDLE

:

8

Hrs.



FULLY CURED

:

7

Days

TEMPRATURE RESISTANCE


:

Tolerant up to 100 Deg Cent Intermediate.

ADHESION



PASSES BY 100%.

MARPROOFNESS


:

Excellent.

REVERSE IMPACT TEST

:

Passes by 1KG/ Sq Cm.

GLOSS VALUE


:

UPTO 60% at 45 Deg Cent.

FLEXIBILITY


:

Passes by ¼ âہ“ Mandrel.

SURFACE HARDNESS


:

Passes by 1.5Kg/ Sq mm.

BOND STRENGTH


:

Passes by 100%.

INSULATION


:

100%.

HEAT TRANSACTION


:

UPTO 80%.

TEMP DURING APPLICATION


:

Upto 45 Deg Cent.

APPLICATION DETAILS

MIXING RATIO

( BY VOLUME )

:

Base

3

:

:

Hardener

1


POT LIFE

:

45 MIN at 25 Deg. C.

APPLICATION METHOD

:

By brush.

THINNER

:

AS 900 Thinner If Required.

INDICATED FILM THICKNESS

:

WET

:

110

Microns



DRY

:

70

Microns

OVERCOATING INTERVAL

:

MIN.

MAX.

:

:

8

24

Hrs.

Hrs.

COMPATIBILITY

:

Can be applied on Copper & MS .

HEALTH & SAFETY

:

Please refer our directive sheet on Health & Safety.


FILM PROPERTY

(RESISTANCE GUIDE)

CHEMICAL RESISTANCE

:

EXPOSURES


ACIDS

ALKALIES

SOLVENTS

SALTS

WATER

SPLASH & SPILLAGE

Very Good

Very Good

Very Good

Very Good

Very Good

FUMES


Very Good

Excellent

Excellent

Excellent

Excellent


TEMPERATURE RESISTANCE

:

CONTINUOUS

INTERMITTENT

:

:

100

120

Deg. C.

Deg. C.

WEATHERABILITY

:

Very Good.

FLEXIBILITY

:

Excellent.

ABRASION RESISTANCE

:

Excellent.


NOTES :




1

Do not apply when temperature rises above 45 Deg. C. and when relative humidity rises above 90 %. Do not apply during rain, fog or mist.



2

Brushes and spray equipment should be cleaned with AS Thinner otherwise equipment is liable to be damaged.


PACKING

:

200 ML , 400 ML , 1000ML & 4000ML.


AVAILABILITY

:

2-3 weeks after receipt of Technically complete purchase order.

SHELF LIFE

:

9 Months (of individual component) - Stored under proper condition of room temp. & pressure. Avoid Direct Sunlight.

DISCLAIMER

:

The information contained in this data sheet is based on Technical data available and from our field experiences. The buyer is requested to verify and ascertain his requirements before application. Due to continuous R & D and improvement in the technology, we reserve our options to change the specifications and presentations.
